Blood Donation – 2D Design: Technical Overview
The Blood Donation – 2D Design provides a detailed and production-ready layout intended for professionals involved in medical facility planning, mobile clinic development, and healthcare infrastructure projects. Prepared in standard DWG format, this design supports precise documentation and seamless integration into architectural and engineering workflows.
This 2D drawing includes essential spatial configurations required for an efficient blood donation environment, such as donor seating arrangements, circulation paths, storage zones, and staff work areas. Each element is drafted with accuracy to ensure compatibility with regulatory dimensions, ergonomic considerations, and operational requirements of blood collection services.
1. GENERAL INFORMATION
| Item |
Specification |
| Project Name |
Mobile Gynecology Clinic – 20ft Container Unit |
| Type |
Modified Shipping Container |
| Container Size |
20ft ISO Standard (High Cube Optional) |
| Application |
Mobile Health Unit – Gynecology Examinations |
| Mobility |
Transportable by truck with twist-lock fittings |
| Deployment |
Temporary or semi-permanent setup |
-
DIMENSIONS
| Parameter |
Specification |
| External Length |
6,058 mm (20 ft) |
| External Width |
2,438 mm |
| External Height |
2,591 mm (Standard) / 2,896 mm (High Cube) |
| Internal Length |
~5,800 mm |
| Internal Width |
~2,300 mm |
| Internal Height |
~2,400 mm (Standard) / ~2,700 mm (High Cube) |
| Floor Load Capacity |
≥ 3,000 kg |
-
STRUCTURE AND MATERIALS
| Component |
Material / Description |
| Container Frame |
Corten Steel (ISO Certified) |
| Wall Insulation |
PU or Rockwool panels (50–75 mm thick) |
| Interior Wall Finish |
Medical-grade antibacterial PVC or HPL panels |
| Flooring |
Vinyl sheet or anti-slip medical-grade floor |
| Roofing |
Weatherproof, insulated steel roof with ceiling |
| Windows |
Double-glazed, tinted windows with mosquito nets |
| Doors |
One main medical-grade entrance + staff entry |
-
INTERIOR LAYOUT (Typical)
| Zone |
Functionality |
| Reception/Waiting Area |
Patient intake, seating for 1–2 patients |
| Examination Room |
Gynecological chair/table, exam equipment |
| Sink Area |
Handwash sink with hot/cold water |
| Cabinets |
Lockable storage for instruments and PPE |
| Doctor’s Workstation |
Desk, chair, laptop, and patient record access |
| Toilet (Optional) |
Compact bio or chemical toilet |
-
ELECTRICAL SYSTEM
| Item |
Specification |
| Power Supply |
220V / 50Hz (Generator or external grid) |
| Lighting |
LED ceiling lights (4000K–5000K) |
| Sockets |
Medical-grade, grounded outlets |
| HVAC |
Split-type air conditioner with heating/cooling |
| Backup Power |
Optional UPS or solar integration |
-
PLUMBING & SANITATION
| Item |
Specification |
| Water Supply |
200–500 L Freshwater Tank |
| Waste Water Tank |
Separate 200–500 L Greywater Tank |
| Pump System |
Electric booster pump (automatic) |
| Toilet (if included) |
Chemical or vacuum toilet system |
-
MEDICAL EQUIPMENT (Basic Setup)
| Item |
Details |
| Gynecology Chair/Table |
Electric or hydraulic adjustable exam chair |
| Ultrasound Machine |
Portable unit (optional) |
| Sterilizer |
Compact tabletop autoclave |
| Medical Lighting |
LED examination light |
| Storage |
Lockable drawers, instrument trays |
-
COMPLIANCE & SAFETY
| Standard |
Description |
| ISO 1496-1 |
Container construction standard |
| Medical Compliance |
WHO Mobile Clinic Guidelines / IEC 60601 |
| Fire Safety |
Fire-rated materials, extinguishers onboard |
| Accessibility |
Optional ramp for wheelchair access |
| Ventilation |
Air vents + exhaust fan for airflow |
-
OPTIONAL ADD-ONS
- Solar panels + inverter system
- CCTV system and remote monitoring
- Exterior branding and signage
- Medical waste bin and disposal unit
- Portable generator
- Internet connectivity (Wi-Fi, 4G router)
