Flanged Threaded Adapter – 3D CAD Model

The Flanged Threaded Adapter is a precision-engineered mechanical component designed to connect threaded piping systems with flanged connections. This 3D CAD model represents a durable and compact adapter suitable for fluid transfer systems, hydraulic assemblies, pneumatic lines, and industrial process applications.

The component features an integrated flange for secure bolted mounting and a threaded end for reliable pipe or fitting connection. Designed with accurate geometry and manufacturing-ready details, the model is ideal for engineering documentation, piping layout design, and production preparation.

Technical Datasheet – Flanged Threaded Adapter

General Specifications

• Component Type: Flanged Threaded Adapter

• Category: Piping / Fluid System Fitting

• Connection Type: Flange × Male/Female Thread

• Thread Standard (Optional): NPT / BSP / Metric

• Pressure Rating: Configurable based on design

• Material Options: Carbon Steel, Stainless Steel (304/316), Brass, Aluminum

Dimensional Parameters (Customizable)

• Nominal Diameter (DN): ½” – 4″ (or metric equivalent)

• Flange Outer Diameter: According to ANSI / DIN standards

• Bolt Hole Pattern: Standard flange configurations

• Thread Length: Adjustable

• Overall Length: Customizable

Design Features

• Integrated flange plate with bolt holes

• Precision threaded section

• Clean and parametric CAD structure

• Manufacturing-ready geometry

• Suitable for CNC machining and casting

File Formats

• SLDPRT / SLDASM

• STEP

• IGES

• DWG (2D optional)

Applications

• Hydraulic systems

• Industrial piping networks

• Oil & gas installations

• Water treatment systems

• Mechanical equipment assembly

Find more related items on Shop section to download for free.
