Shower and Toilet Cabin | 3D CAD Model for Modular Sanitary Solutions

General Description

The Shower and Toilet Cabin is a self-contained modular sanitation unit engineered for construction sites, mobile clinics, remote facilities, and disaster-relief operations. The design integrates separate toilet and shower sections within a compact, durable cabin structure optimized for hygiene, portability, and ease of installation.

Technical Specifications of Shower

• Overall Dimensions: 2.4 m (L) × 1.5 m (W) × 2.5 m (H)

• Frame Material: Galvanized steel / aluminum profiles

• Wall & Roof Panels: Sandwich-type insulated composite panels

• Flooring: Anti-slip PVC or GRP floor with integrated drain system

• Plumbing: Integrated fresh & grey water tanks, quick-connect fittings

• Electrical System: 220V power input, LED lighting, water heater compatible

• Ventilation: Roof vent and optional exhaust fan

• Doors & Fixtures: Lockable steel doors, stainless-steel taps and shower head

Design & CAD Model Features

• File Types: SolidWorks part & assembly, STEP neutral format

• Detailed 3D geometry: internal partitions, plumbing layout, fixtures, and structural framing

• Parametric design: customizable cabin size and component materials

• Manufacturing-ready model: accurate dimensions for fabrication and assembly drawings

• Compatible with BIM / AEC workflows

Applications

• Construction site sanitation

• Field hospitals and mobile clinics

• Emergency response shelters

• Event or camp facility infrastructure.
