Emergency Trolley – CAD Models and Technical Specifications

Product Overview

The Emergency Trolley CAD Models provide detailed 2D and 3D representations for engineers, architects, and students. Designed for hospitals, clinics, and healthcare facilities, these models enable precise planning, space optimization, and integration with medical workflows.

Technical Specifications

Dimensions

• Standard Size: Width 600 mm, Depth 500 mm, Height 900 mm

• Parametric CAD Models: Adjustable for specific requirements or custom designs

Materials & Construction

• Frame: Stainless steel or powder-coated aluminum

• Drawers & Compartments: ABS plastic or stainless steel, modular design

• Top Surface: Laminated or anti-microbial finish

• Wheels: Lockable swivel casters for mobility and stability

Functional Features

• Storage Layout: Multiple drawers for emergency drugs, instruments, and supplies

• Equipment Holders: Hooks or brackets for oxygen cylinders, suction units, and monitors

• Electrical Integration: Optional CAD layouts for built-in power strips and device charging

• Ergonomic Design: Height and handle placement optimized for quick access

CAD Formats Available

• DWG (2D technical drawings)

• RVT (Revit Family for BIM integration)

• STEP/IGES (Mechanical assembly and fabrication)

• STL (3D printing and prototyping)

Applications

• Healthcare Facilities: Emergency rooms, ICUs, and surgical suites

• Mobile Clinics: Portable design for field hospitals and rapid deployment units

• Training & Education: Hands-on CAD practice for biomedical engineering and interior layout planning

Key Features

• High-Precision CAD Models for accurate spatial and mechanical integration

• Parametric Design allows resizing and customization

• BIM Compatible for seamless integration with healthcare facility planning

• Detailed Functional Layouts including drawers, handles, and mobility systems

More Healthcare drawings can be found on CAD Store.
